Steel Doors & Steel Doorsets

Armourdoor AD60
Acoustic Soundproof Steel Door

An acoustic soundproof steel door designed for soundproofing whilst providing a medium level of security.

Tested to EN ISO 717-1, the door is manually operated and can provide an acoustic reduction of 35 dB, 45 dB or 50 dB.  Available in single or double openings at recommended heights of up to 2900 mm.

HOW WE RATE THIS DOOR

HOW THIS DOOR IS COMMONLY USED

Product Specification

Product Overview

Operation

The armourdoor acoustic soundproof steel door comes as a manual operation.

Dimensions:

Single openings from 690mm to 1390mm
Double openings from 1290mm to 2600mm
All at heights up to 2900mm

Finish

The Armourdoor Acoustic Door AD60 is available powder coated from a standard range of colours. Wood grain, PVC Laminate and Stainless steel are available.

Specification of Build

The armourdoor acoustic soundproof steel door AD 60 has a leaf thickness of 56mm and an infill rock wool. Door Frame constructed from folded 1.6mm Magnelis steel. The acoustic door is supplied with a variable sub frame to allow up to 30mm tolerance for site installations. The frame is fitted with 1 dog bolt hinge as standard.

Product specification may change and it is advisable to consult with HAG technical advisors before specifying or ordering. HAG operates a policy of continuous improvement.

The advantage of acoustic doors

In most professional settings, there will always be a combination of areas that are private and others that are public. For example, a hospital will have an open waiting area for patients and visitors and at the same time have offices where exams and consultations take place. Acoustic door In order for a workplace to adapt its space for its operational needs, there has to be a way to separate the private and public spaces. Acoustic doors are a great solution in situations where a quiet space is needed for working or holding conversations. Here are some of the benefits of acoustic doors:

Noise reduction

Acoustic doors are a great way to ensure that details of private meetings are not heard by people outside the room. They also minimise the noise entering a room when quiet is essential. Areas that would benefit from using acoustic doors due to their high degree of noise insulation include studios, schools and offices. In addition to reducing noise levels.

Privacy

With acoustic doors, any interactions that are private are confined to the right space. A healthcare facility, executive offices or a human resource office can definitely use acoustic doors too as they provided the much-needed privacy required. Even in a setting where having an open floor is promoted such as a high-tech business, an acoustic door made with clear glass can help maintain openness while still keeping conversations private.

Variety of different applications

Acoustic doors come in different grades for use in assorted applications. An acoustic door in a music recording studio will keep out unwanted noise that should be avoided in a recording session. A glass acoustic door will help the interaction between the engineer and the producer as they need to see each other while still minimising the noise in the space. A conference room is another logical application for an acoustic door. In a corporate office, there are always discussions that may be discussed that require absolute confidentiality. In production departments, there are always machines running, making a lot of noise. Acoustic doors are the best way to keep the noise levels low in offices near heavy machinery.

Different standards of noise reduction

There are two standard acoustic ratings for acoustic doors. There are two major versions available, the high-performance version and the low-performance version. The high-performance version has a noise reduction value of 44dB while the medium performance version has a noise reduction value of 34dB. Other acoustic ratings can be made available on request.

Acoustic doors can be customised

This is another great advantage of acoustic doors. An acoustic door can be fitted in any space size in many different finishes. You can use glass for visibility and openness or wood to go along with the office design. Aluminium can also be used. As long as you work with professional installers like HAG, an acoustic door is definitely the way to go due to the many available benefits that they provide. Get in touch with our experienced team by calling us on 0800 072 3444 or fill out our contact form.
