Product Specification
Product Overview
The SeceuroGlide roller garage doors are manufactured from a double skinned insulated foam filled aluminium slat with webbing cushion ends to enhance noise reduction and prevent excessive marking.
The patented integral locking system, safety facility with remote control operation, and variable security conscious guide options complete a combination that provides the ultimate rolling garage door.
Box Description
Seceuroglide garage doors are constructed from double skin foam filled aluminium slat.
Common use
Roller Garage Doors for domestic properties
Maximum Width
5400mm
Dimensions
Nominally 77mm high x 19mm thick.
Weight
6kg per square metre.
Finish
White, brown, light beige, burgundy red, fir green or black & medium woodgrain (surcharges apply)
Shutter Box Specification
Construction
Roll formed aluminium in two sections; top and bottom boxes. Bottom box removable for installation and maintenance and chamfered 45 degrees.
Box sizes
Clear opening height (to underside of box):
2500mm box size 300mm
3500mm box side 350mm
Finish
White, dark brown, Alternative standard RAL or BS colours at an
Guide Rail Specification
Construction
Extruded aluminium with an integral box section for reinforcement and to facilitate fixing. Neoprene seals for quiet and smooth operation.
Dimensions
75mm wide x 34mm deep up to 4600mm wide
90mm wide x 34mm deep up to 5200mm wide
Finish
White, brown, light beige, burgundy red, fir green or black.
Acoustics
(Insulation 2.8 watts per m2 Kelvin w/m2k
Decibel reduction at 500HZ = 18 dB
Decibel reduction at 1000HZ = 25 dB
Single phase Electric
Provision of a 13 amp fused spur is required for installation A tubular motor within the barrel assembly with limit switches and the thermal cut out to prevent overheating. Draw 240 volts and 0.5 – 2.5 amps dependant upon the shutter size.
Control
Seceurosmart Remote Control unit with 2 Hand transmitters, Wireless Safety edge, internal manual override and light.
Product specification may change and it is advisable to consult with HAG technical advisors before specifying or ordering. HAG operates a policy of continuous improvement.
